Carbon Steel Tube Production Line Square ERW Pipe Mill Making Machine

Name: Carbon Steel Tube Production Line Square ERW Pipe Mill Making Machine
Brand: ZTZG
Price: 1 USD

China Carbon Steel Tube Production Line Square ERW Pipe Mill Making Machine wholesale

Brand Name : ZTZG

Model Number : ERW89

Certification : ISO9001

Place of Origin : China

MOQ : 1

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 200 sets/year

Delivery Time : 90 days

Packaging Details : All mechanical equipment is nude packing and electrical parts are packed in wooden cases

Product Name : ERW20 High Frequency Straight Welded Pipe Production Line Square Tube Mill

Shape : Square

Raw Material : Carbon Steel Coil

Length : 6-12 m

Thickness : 1.5mm-4.5mm

Voltage : 220/380/415/420/440V

Power(w) : 150 kw

Worker : 6-8 Workers

After-sales service provided : Engineers available to service machinery overseas,Online support

Application : Construction,Furniture

Useful life : 30 years for Steel Tube Mill

Service : Free technical consultation

Contact Now

Carbon Steel Tube Production Line Square ERW Pipe Mill Making Machine

ERW89 high frequency longitudinal welded pipe production line / pipe making machine / tube mill is designed to produce welded pipes of 42mm-89mm in OD and 1.5mm-4.5mm in wall thickness, as well as corresponding square and rectangular pipe.

Carbon Steel Tube Production Line Square ERW Pipe Mill Making Machine

Advantage:

Low wastage, low unit wastage and low production cost.
High yielding, the machine works stably at a high speed, which improves the yielding of products.

High production efficiency, line speed can be up to 120m/min.
High accuracy, diameter error is only 0.5/100 of the pipe OD.

Carbon Steel Tube Production Line Square ERW Pipe Mill Making Machine

Basic Technical Information of Welded Pipe Production Line
Product&yield	Round Pipe	42mm-89mm Thickness:1.5mm-4.5mm
	Square & rectangle tube	35mm×35mm -70mm×70mm Thickness:1.5mm-3.5mm
	Length	6m-12m Length Tolerance: ±3mm
	Production Speed	20-110 m/min
	Production capacity	22,000ton/year
Consumption	Mill installed capacity	150 kw
	Line Area	72m(length) ×5.5m (width)
	worker	6-8 workers
Raw Material	Carbon Steel coil	GB/T 700: Q235B(ASTM: GR·D(σs 230) / JIS: SS400)
	Width	130mm-280mm Thickness: 1.5mm-4.5mm
	Coil ID	550-610mm
	Coil OD	Max 1600mm
	Coil Weight	4.0t

Technical flow

Scrolling up→ Uncoiling → Shear and Welding→ Spiral accumulator→ Forming → H.F. induction welding→ External burr removing→ Cooling → Sizing→ Flying saw → Run out table →Inspecting→ Packing→ Warehouse

We can also design square tube machine depends on customer’s requirement.
